Installing Gentoo Linux on Apple Silicon Mac (M1/M2/M3/M4 Complete Guide)

Installation Process Overview (Simplified)

#

Required Steps:

1. Download official Gentoo Asahi Live USB image
2. Configure U-Boot environment via Asahi installer
3. Boot from Live USB
4. Partition disk and mount filesystems
5. Unpack Stage3 and enter chroot
6. Install Asahi support packages (automated script)
7. Reboot to finish installation

Optional Steps:

• LUKS Encryption (Recommended but not mandatory)
• Custom kernel configuration (Default dist-kernel is fine)
• Audio setup (PipeWire, as needed)
• Desktop environment selection

The entire process will create a dual-boot environment on your Mac: macOS + Gentoo Linux ARM64.

Prerequisites and Notes

#

0. Prepare Gentoo Asahi Live USB

#

0.1 Download Official Gentoo Asahi Live USB

#

Official Simplified Process: Use the Gentoo provided ARM64 Live USB directly, no need to go through Fedora!

Download latest version:

# Method 1: Author's site download
https://chadmed.au/pub/gentoo/

0.2 Create Bootable USB

#

In macOS:

# Check USB device name
diskutil list

# Unmount USB (assuming /dev/disk4)
diskutil unmountDisk /dev/disk4

# Write image (note using rdisk is faster)
sudo dd if=install-arm64-asahi-*.iso of=/dev/rdisk4 bs=4m status=progress

# Eject after completion
diskutil eject /dev/disk4

1. Configure Asahi U-Boot Environment

#

1.1 Run Asahi Installer

#

Run in macOS Terminal:

curl https://alx.sh | sh

1.2 Follow Installer Steps

#

The installer will guide you:

1. Choose Action: Enter r (Resize an existing partition to make space for a new OS)

2. Choose Partition Space: Decide space allocated for Linux (Recommended at least 80 GB)

   • Can use percentage (e.g., 50%) or absolute size (e.g., 120GB)

3. Choose OS: Select UEFI environment only (m1n1 + U-Boot + ESP)

   » OS: <Select UEFI only option>


4. Set Name: Enter Gentoo as OS name

   » OS name: Gentoo


5. Finish Installation: Note screen instructions, then press Enter to shut down.

1.3 Complete Recovery Mode Setup (Critical Step)

#

Important Reboot Steps:

1. Wait 25 seconds to ensure system is fully shut down
2. Hold Power Button until you see "Loading startup options..." or spinning icon
3. Release Power Button
4. Wait for volume list to appear, select Gentoo
5. You will see macOS Recovery screen:
   • If asked "Select a volume to recover", select your macOS volume and click Next
   • Enter macOS user password (FileVault users)
6. Follow screen instructions to complete setup

2. Boot from Live USB

#

2.1 Connect Live USB and Boot

#

1. Insert Live USB (Can use USB Hub or Dock)
2. Boot Mac
3. U-Boot Auto Boot:
   • If "UEFI environment only" was selected, U-Boot will automatically boot GRUB from USB
   • Wait 2 seconds for auto boot sequence
   • If multiple systems exist, might need to interrupt and manually select

setenv boot_targets "usb"
setenv bootmeths "efi"
boot

2.2 Configure Network (Live Environment)

#

Gentoo Live USB built-in network tools:

Wi-Fi Connection:

net-setup

Follow interactive prompts to set up network. Check after completion:

ping -c 3 www.gentoo.org

(Optional) SSH Remote Operation:

passwd                     # Set root password
/etc/init.d/sshd start
ip a | grep inet          # Get IP address

3. Partition and Filesystem Setup

#

3.1 Identify Disk and Partitions

#

View partition structure:

lsblk
blkid --label "EFI - GENTO"  # Check your EFI partition

Usually you will see:

NAME        MAJ:MIN RM   SIZE RO TYPE MOUNTPOINTS
loop0         7:0    0 609.1M  1 loop /run/rootfsbase
sda           8:0    1 119.5G  0 disk /run/initramfs/live
|-sda1        8:1    1   118K  0 part
|-sda2        8:2    1   2.8M  0 part
`-sda3        8:3    1 670.4M  0 part
nvme0n1     259:0    0 465.9G  0 disk
|-nvme0n1p1 259:1    0   500M  0 part
|-nvme0n1p2 259:2    0 307.3G  0 part
|-nvme0n1p3 259:3    0   2.3G  0 part
|-nvme0n1p4 259:4    0   477M  0 part
`-nvme0n1p5 259:5    0     5G  0 part
nvme0n2     259:6    0     3M  0 disk
nvme0n3     259:7    0   128M  0 disk

EFI Partition Identification (Do not touch this partition!):

livecd ~ # blkid --label "EFI - GENTO"
/dev/nvme0n1p4  # This is the EFI partition, do not touch

3.2 Create Root Partition

#

Assuming free space starts from /dev/nvme0n1p5:

Method A: Simple Partition (No Encryption)

# Use cfdisk to create new partition
cfdisk /dev/nvme0n1

You will see a partition table similar to:

                                            Disk: /dev/nvme0n1
                         Size: 465.92 GiB, 500277792768 bytes, 122138133 sectors
                       Label: gpt, identifier: 6C5A96F2-EFC9-487C-8C3E-01FD5EA77896

    Device                      Start            End       Sectors        Size Type
    /dev/nvme0n1p1                  6         128005        128000        500M Apple Silicon boot
    /dev/nvme0n1p2             128006       80694533      80566528      307.3G Apple APFS
    /dev/nvme0n1p3           80694534       81304837        610304        2.3G Apple APFS
    /dev/nvme0n1p4           81304838       81426949        122112        477M EFI System
>>  Free space               81427200      120827418      39400219      150.3G
    /dev/nvme0n1p5          120827419      122138127       1310709          5G Apple Silicon recovery

                        [   New  ]  [  Quit  ]  [  Help  ]  [  Write ]  [  Dump  ]

                                   Create new partition from free space

Steps:

1. Select Free space → New
2. Use all space (or custom size)
3. Type → Select Linux filesystem
4. Write → Type yes to confirm
5. Quit to leave

Format Partition:

# Format as ext4 or btrfs
mkfs.ext4 /dev/nvme0n1p6
# Or
mkfs.btrfs /dev/nvme0n1p6

# Mount
mount /dev/nvme0n1p6 /mnt/gentoo

Method B: Encrypted Partition (Optional, Recommended)

# Create LUKS2 encrypted partition
cryptsetup luksFormat --type luks2 --pbkdf argon2id --hash sha512 --key-size 512 /dev/nvme0n1p6

# Type YES to confirm, set encryption password

# Open encrypted partition
cryptsetup luksOpen /dev/nvme0n1p6 gentoo-root

# Format
mkfs.btrfs --label root /dev/mapper/gentoo-root

# Mount
mount /dev/mapper/gentoo-root /mnt/gentoo

3.3 Mount EFI Partition

#

mkdir -p /mnt/gentoo/boot
mount /dev/nvme0n1p4 /mnt/gentoo/boot

4. Stage3 and chroot

#

4.1 Download and Unpack Stage3

#

cd /mnt/gentoo

# Download latest ARM64 Desktop systemd Stage3
wget https://distfiles.gentoo.org/releases/arm64/autobuilds/current-stage3-arm64-desktop-systemd/stage3-arm64-desktop-systemd-*.tar.xz

# Unpack (preserve attributes)
tar xpvf stage3-*.tar.xz --xattrs-include='*.*' --numeric-owner

4.2 Configure Portage

#

mkdir --parents /mnt/gentoo/etc/portage/repos.conf
cp /mnt/gentoo/usr/share/portage/config/repos.conf /mnt/gentoo/etc/portage/repos.conf/gentoo.conf

4.3 Sync System Time (Important)

#

Before entering chroot, ensure system time is correct (to avoid compilation and SSL certificate issues):

# Sync time
chronyd -q

# Verify time is correct
date

4.4 Enter chroot Environment

#

Mount necessary filesystems:

cp --dereference /etc/resolv.conf /mnt/gentoo/etc/
mount --types proc /proc /mnt/gentoo/proc
mount --rbind /sys /mnt/gentoo/sys
mount --make-rslave /mnt/gentoo/sys
mount --rbind /dev /mnt/gentoo/dev
mount --make-rslave /mnt/gentoo/dev
mount --bind /run /mnt/gentoo/run
mount --make-slave /mnt/gentoo/run

Enter chroot:

chroot /mnt/gentoo /bin/bash
source /etc/profile
export PS1="(chroot) ${PS1}"

4.5 Basic System Configuration

#

Configure make.conf (Optimized for Apple Silicon):

Edit /etc/portage/make.conf:

nano -w /etc/portage/make.conf

Add or modify the following:

# vim: set language=bash;
CHOST="aarch64-unknown-linux-gnu"

# Apple Silicon Optimized Compilation Flags
COMMON_FLAGS="-march=armv8.5-a+fp16+simd+crypto+i8mm -mtune=native -O2 -pipe"
CFLAGS="${COMMON_FLAGS}"
CXXFLAGS="${COMMON_FLAGS}"
FCFLAGS="${COMMON_FLAGS}"
FFLAGS="${COMMON_FLAGS}"
RUSTFLAGS="-C target-cpu=native"

# Keep build output in English (Please keep this for error reporting)
LC_MESSAGES=C

# Adjust based on hardware (e.g., M2 Max has more cores)
MAKEOPTS="-j4"

# Gentoo Mirrors (Recommended to use R2 mirror for speed)
GENTOO_MIRRORS="https://gentoo.rgst.io/gentoo"

# Emerge Default Options (Compile at most 3 packages simultaneously)
EMERGE_DEFAULT_OPTS="--jobs 3"

# Asahi GPU Driver
VIDEO_CARDS="asahi"

# Localization Support (Optional)
L10N="en en-US"

# Keep newline at end of file! Important!

Sync Portage:

emerge-webrsync

Set Timezone:

# Set to your timezone (e.g., America/New_York)
ln -sf /usr/share/zoneinfo/America/New_York /etc/localtime

Set Locale:

# Edit locale.gen, uncomment needed locales
nano -w /etc/locale.gen
# Uncomment: en_US.UTF-8 UTF-8

# Generate locales
locale-gen

# Select system default locale
eselect locale set en_US.utf8

# Reload environment
env-update && source /etc/profile && export PS1="(chroot) ${PS1}"

Create User and Set Password:

# Create user (Replace <username> with your username)
useradd -m -G wheel,audio,video,usb,input <username>

# Set user password
passwd <username>

# Set root password
passwd root

5. Install Asahi Support Packages (Core Step)

#

5.1 Method A: Automated Installation (Recommended)

#

Step 1: Install git

# Sync Portage tree for the first time
emerge --sync

# Install git (required for downloading script)
emerge --ask dev-vcs/git

Step 2: Use asahi-gentoosupport script (Official):

cd /tmp
git clone https://github.com/chadmed/asahi-gentoosupport
cd asahi-gentoosupport
./install.sh

This script will automatically:

• Enable Asahi overlay
• Install GRUB bootloader
• Set VIDEO_CARDS="asahi"
• Install asahi-meta (includes kernel, firmware, m1n1, U-Boot)
• Run asahi-fwupdate and update-m1n1
• Update system

# When script prompts for USE flag conflict, press Ctrl+C to interrupt
# Then run:
emerge --autounmask-write <package-with-conflict>

# Update configuration files
etc-update
# Select appropriate option in etc-update (usually -3 for auto-merge)

# Re-run installation script
cd /tmp/asahi-gentoosupport
./install.sh

Skip directly to Step 5.3 (fstab configuration) after script completion!

5.2 Method B: Manual Installation (Advanced Users)

#

Step 1: Install git and configure Asahi overlay

# Sync Portage tree for the first time
emerge --sync

# Install git (for git sync method)
emerge --ask dev-vcs/git

# Remove old Portage repository and switch to git sync
rm -rf /var/db/repos/gentoo
sudo tee /etc/portage/repos.conf/gentoo.conf << 'EOF'
[DEFAULT]
main-repo = gentoo

[gentoo]
location = /var/db/repos/gentoo
sync-type = git
sync-uri = https://github.com/gentoo-mirror/gentoo.git
auto-sync = yes
sync-depth = 1
EOF

# Configure Asahi overlay using git sync
sudo tee /etc/portage/repos.conf/asahi.conf << 'EOF'
[asahi]
location = /var/db/repos/asahi
sync-type = git
sync-uri = https://github.com/chadmed/asahi-overlay.git
auto-sync = yes
EOF

# Sync all repositories
emerge --sync

Step 2: Configure package.mask (Important!)

Prevent Gentoo official dist-kernel from overwriting Asahi version:

mkdir -p /etc/portage/package.mask
cat > /etc/portage/package.mask/asahi << 'EOF'
# Mask the upstream dist-kernel virtual so it doesn't try to force kernel upgrades
virtual/dist-kernel::gentoo
EOF

Step 3: Configure package.use

mkdir -p /etc/portage/package.use

# Asahi specific USE flags
cat > /etc/portage/package.use/asahi << 'EOF'
dev-lang/rust-bin rustfmt rust-src
dev-lang/rust rustfmt rust-src
EOF

# VIDEO_CARDS setting
echo 'VIDEO_CARDS="asahi"' >> /etc/portage/make.conf

# GRUB platform setting (Required!)
echo 'GRUB_PLATFORMS="efi-64"' >> /etc/portage/make.conf

Step 4: Configure firmware license

mkdir -p /etc/portage/package.license
echo 'sys-kernel/linux-firmware linux-fw-redistributable no-source-code' > /etc/portage/package.license/firmware

Step 5: Install rust-bin (Must install first!)

emerge -q1 dev-lang/rust-bin

Step 6: Install Asahi packages

# Install all necessary packages at once
emerge -q sys-apps/asahi-meta virtual/dist-kernel:asahi sys-kernel/linux-firmware

Package explanation:

• rust-bin: Required for compiling Asahi kernel components (must install first)
• asahi-meta: Includes m1n1, asahi-fwupdate, U-Boot tools
• virtual/dist-kernel:asahi: Asahi custom kernel (includes non-upstream patches)
• linux-firmware: Provides hardware firmware like Wi-Fi

Step 7: Update firmware and bootloader

asahi-fwupdate
update-m1n1

Step 8: Install and Configure GRUB

# Install GRUB
emerge -q grub:2

# Install GRUB to ESP (Note: --removable flag is important!)
grub-install --boot-directory=/boot/ --efi-directory=/boot/ --removable

# Generate GRUB config
grub-mkconfig -o /boot/grub/grub.cfg

Step 9: Update System (Optional)

emerge --ask --update --deep --changed-use @world

5.3 Configure fstab

#

Get UUIDs:

blkid $(blkid --label root)       # Root partition (or /dev/mapper/gentoo-root)
blkid $(blkid --label "EFI - GENTO")     # boot partition

Edit /etc/fstab:

nano -w /etc/fstab

# Root partition (Adjust according to your config)
UUID=<your-root-uuid>  /      ext4   defaults  0 1
# Or encrypted version:
# UUID=<your-btrfs-uuid>  /      btrfs  defaults  0 1

UUID=<your-boot-uuid>  /boot  vfat   defaults  0 2

5.4 Configure Encryption Support (Encrypted Users Only)

#

Step 1: Enable systemd cryptsetup support

mkdir -p /etc/portage/package.use
echo "sys-apps/systemd cryptsetup" >> /etc/portage/package.use/fde

# Recompile systemd to enable cryptsetup support
emerge --ask --oneshot sys-apps/systemd

Step 2: Get LUKS Partition UUID

# Get LUKS encrypted container UUID (Not the filesystem UUID inside)
blkid /dev/nvme0n1p5

Output example:

/dev/nvme0n1p5: UUID="a1b2c3d4-e5f6-7890-abcd-ef1234567890" TYPE="crypto_LUKS" ...

Note down this LUKS UUID (e.g., a1b2c3d4-e5f6-7890-abcd-ef1234567890).

Step 3: Configure GRUB Kernel Parameters

nano -w /etc/default/grub

Add or modify the following (Replace UUID with actual values):

# Complete Example (Replace UUID with your actual UUID)
GRUB_CMDLINE_LINUX="rd.luks.uuid=3f5a6527-7334-4363-9e2d-e0e8c7c04488 rd.luks.allow-discards root=UUID=f3db74a5-dc70-48dd-a9a3-797a0daf5f5d rootfstype=btrfs"

Step 4: Install and Configure dracut

# Install dracut (if not installed)
emerge --ask sys-kernel/dracut

Step 5: Configure dracut for LUKS decryption

Create dracut config file:

nano -w /etc/dracut.conf.d/luks.conf

Add the following:

# Do not set kernel_cmdline here, GRUB will overwrite it
kernel_cmdline=""
# Add necessary modules to support LUKS + btrfs
add_dracutmodules+=" btrfs systemd crypt dm "
# Add necessary tools
install_items+=" /sbin/cryptsetup /bin/grep "
# Specify filesystem (Modify if using other filesystem)
filesystems+=" btrfs "

Step 6: Configure /etc/crypttab (Optional but Recommended)

nano -w /etc/crypttab

Add the following (Replace UUID with your LUKS UUID):

gentoo-root UUID=<LUKS-UUID> none luks,discard

Step 7: Regenerate initramfs

# Get current kernel version
dracut --kver $(make -C /usr/src/linux -s kernelrelease) --force

Step 8: Update GRUB Config

grub-mkconfig -o /boot/grub/grub.cfg

# Verify initramfs is correctly referenced
grep initrd /boot/grub/grub.cfg

6. Finish Installation and Reboot

#

6.1 Final Settings

#

Set Hostname:

echo "macbook" > /etc/hostname

Enable NetworkManager (Desktop System):

systemctl enable NetworkManager

Set root password (If not set):

passwd root

6.2 Exit chroot and Reboot

#

exit
umount -R /mnt/gentoo
# If using encryption:
```bash
cryptsetup luksClose gentoo-root

reboot

6.3 First Boot

#

1. U-Boot will start automatically
2. GRUB menu appears, select Gentoo
3. (If encrypted) Enter LUKS password
4. System should successfully boot to login prompt

7. Post-Installation Configuration (Optional)

#

7.1 Network Connection

#

# Wi-Fi
nmcli device wifi connect <SSID> password <password>

# Or use nmtui (GUI)
nmtui

7.2 Install Desktop Environment (Optional)

#

Step 1: Check and Select System Profile

#

# List all available profiles
eselect profile list

Output example:

Available profile symlink targets:
  [1]   default/linux/arm64/23.0 (stable)
  [2]   default/linux/arm64/23.0/systemd (stable) *
  [3]   default/linux/arm64/23.0/desktop (stable)
  [4]   default/linux/arm64/23.0/desktop/gnome (stable)
  [5]   default/linux/arm64/23.0/desktop/gnome/systemd (stable)
  [6]   default/linux/arm64/23.0/desktop/plasma (stable)
  [7]   default/linux/arm64/23.0/desktop/plasma/systemd (stable)

Select appropriate profile:

# GNOME Desktop
eselect profile set 5    # desktop/gnome/systemd

# KDE Plasma Desktop (Recommended)
eselect profile set 7    # desktop/plasma/systemd

# Generic Desktop Environment (Xfce etc.)
eselect profile set 3    # desktop (No specific desktop)

Step 2: Update System to Apply New Profile

#

After switching profile, need to recompile affected packages:

# Update all packages to apply new USE flags
emerge -avuDN @world

Step 3: Install Desktop Environment

#

Option A: KDE Plasma (Recommended)

# Install KDE Plasma Desktop
emerge --ask kde-plasma/plasma-meta kde-apps/kate kde-apps/dolphin

# Enable Display Manager
systemctl enable sddm

# Install common apps (Optional)
emerge --ask kde-apps/konsole \
             kde-apps/okular \
             www-client/firefox

Option B: GNOME

# Install full GNOME Desktop
emerge --ask gnome-base/gnome gnome-extra/gnome-tweaks

# Enable Display Manager
systemctl enable gdm

# Install common apps (Optional)
emerge --ask gnome-extra/gnome-system-monitor \
             gnome-extra/gnome-calculator \
             www-client/firefox

Option C: Xfce (Lightweight)

# Switch back to generic desktop profile first
eselect profile set 3    # desktop

# Update system
emerge -avuDN @world

# Install Xfce
emerge --ask xfce-base/xfce4-meta xfce-extra/xfce4-pulseaudio-plugin

# Install and enable Display Manager
emerge --ask x11-misc/lightdm
systemctl enable lightdm

Step 4: Optimize Desktop Performance (Optional)

#

Enable Video Acceleration (Asahi GPU):

# Check VIDEO_CARDS setting
grep VIDEO_CARDS /etc/portage/make.conf
# Should contain: VIDEO_CARDS="asahi"

# Install Mesa and Asahi drivers (Usually already installed)
emerge --ask media-libs/mesa

Enable Font Rendering:

# Install basic fonts
emerge --ask media-fonts/liberation-fonts \
             media-fonts/noto \
             media-fonts/noto-cjk \
             media-fonts/dejavu

# Enable font tweaking
eselect fontconfig enable 10-sub-pixel-rgb.conf
eselect fontconfig enable 11-lcdfilter-default.conf

Chinese Input Method Configuration:

# Install Fcitx5 Chinese Input Method
emerge --ask app-i18n/fcitx-chinese-addons

7.3 Audio Configuration (Optional)

#

Asahi audio is provided via PipeWire. Install and enable related services:

# Install Asahi audio support
emerge --ask media-libs/asahi-audio

# Enable PipeWire services
systemctl --user enable --now pipewire-pulse.service
systemctl --user enable --now wireplumber.service

8. System Maintenance

#

8.1 Regular Update Process

#

# Update Portage tree (Includes Asahi overlay)
emerge --sync
# Or manually sync Asahi overlay:
emaint -r asahi sync

# Update all packages
emerge -avuDN @world

# Clean up unneeded packages
emerge --depclean

# Update config files
dispatch-conf

8.2 Must-Do After Kernel Update

#

# Update m1n1 Stage 2 (Includes devicetree)
update-m1n1

# Regenerate GRUB config
grub-mkconfig -o /boot/grub/grub.cfg

Why? m1n1 Stage 2 contains devicetree blobs, kernel needs it to identify hardware. Failure to update may cause boot failure or missing features.

8.3 Update Firmware

#

macOS system updates include firmware updates. Recommended to keep macOS partition to get latest firmware.

9. FAQ and Troubleshooting

#

Problem: Cannot boot from USB

#

Possible Cause: U-Boot USB driver limitations.

Solution:

• Try different USB flash drive
• Use USB 2.0 device (Better compatibility)
• Connect via USB Hub

Problem: Boot stuck or black screen

#

Cause: m1n1/U-Boot/Kernel mismatch.

Solution:

1. Re-run Asahi installer from macOS
2. Select p option to retry Recovery process
3. Ensure update-m1n1 was executed in chroot

Problem: Encrypted partition cannot unlock

#

Cause: dracut config error or wrong UUID.

Solution:

1. Check GRUB_CMDLINE_LINUX in /etc/default/grub
2. Confirm correct LUKS UUID: blkid /dev/nvme0n1p5
3. Regenerate GRUB config: grub-mkconfig -o /boot/grub/grub.cfg

Problem: Unstable Wi-Fi

#

Cause: Possible WPA3 or 6 GHz band issues.

Solution:

• Connect to WPA2 network
• Use 2.4 GHz or 5 GHz band (Avoid 6 GHz)

Problem: Trackpad not working

#

Cause: Firmware not loaded or driver issue.

Solution:

# Check firmware
dmesg | grep -i firmware

# Ensure asahi-meta is installed
emerge --ask sys-apps/asahi-meta

10. Advanced Tips (Optional)

#

10.1 Notch Configuration

#

Default notch area shows as black. To enable:

# Add to GRUB kernel parameters
apple_dcp.show_notch=1

KDE Plasma Optimization:

• Add full-width panel at top, height aligned to notch bottom
• Left: Application Dashboard, Global menu, Spacer
• Right: System Tray, Bluetooth, Power, Clock

10.2 Custom Kernel (Advanced)

#

Using Distribution kernel is fine, but if you want to customize:

emerge --ask sys-kernel/asahi-sources
cd /usr/src/linux
make menuconfig
make -j$(nproc)
make modules_install
make install
update-m1n1  # Must!
grub-mkconfig -o /boot/grub/grub.cfg

10.3 Multi-Kernel Switching

#

Supports multiple kernels coexistence:

eselect kernel list
eselect kernel set <number>
update-m1n1  # Must execute after switching!

11. References

#

Conclusion

#
