Gentoo Linux Installation Guide (Base)
  1. Posts/

Gentoo Linux Installation Guide (Base)

··31 mins· loading · ·
Zakkaus
Tutorial Gentoo Linux Tutorial System Installation
Zakk
Author
Zakk
Studying business in Australia, having a long-distance relationship with Paper, raising potatoes and hash browns, and writing Linux notes and life journals.
Table of Contents

Special Note
#

This article is the first part of the Gentoo Linux Installation Guide series: Base Installation.

Series Navigation:

  1. Base Installation (This Article): Install Gentoo base system from scratch
  2. Desktop Configuration: Graphics drivers, Desktop Environments, Input methods, etc.
  3. Advanced Optimization: make.conf optimization, LTO, System maintenance

Recommended Reading Path:

  • Read as needed: Base Installation (Sections 0-11) → Desktop Configuration (Section 12) → Advanced Optimization (Sections 13-17)

About This Guide
#

This article aims to provide a complete Gentoo installation process demonstration and intensively provides references for learning. The article contains a large number of official Wiki links and technical documents to help readers deeply understand the principles and configuration details of each step.

This is not a simple dummy tutorial, but a guiding learning resource — the first step in using Gentoo is to learn to read the Wiki and solve problems yourself, and make good use of Google or even AI tools to find answers. When encountering problems or needing to understand in depth, please be sure to consult the official handbook and the reference links provided in this article.

If you have questions or find issues during reading, welcome to raise them through the following channels:

Highly recommended to follow the official handbook:

✓ Verified as of November 25, 2025

What is Gentoo?
#

Gentoo Linux is a source-based Linux distribution known for its high customizability and performance optimization. Unlike other distributions, Gentoo lets you compile all software from source code, which means:

  • Extreme Performance: All software is optimized and compiled for your hardware
  • Total Control: You decide what the system contains and what it doesn't
  • Deep Learning: Deeply understand Linux by building the system yourself
  • Compilation Time: Initial installation takes a long time (Recommended to reserve 3-6 hours)
  • Learning Curve: Requires some Linux basic knowledge

Who is it for?

  • Tech enthusiasts who want to learn Linux deeply
  • Users pursuing system performance and customization
  • Geeks who enjoy the DIY process

Who is it not for?

  • Beginners who just want to install and use quickly (Recommended to try Ubuntu, Fedora first)
  • Users who don't have time to tinker with the system
Core Concepts at a Glance (Click to expand)

Before starting installation, understand a few core concepts:

Stage3 (Wiki) A minimal Gentoo base system archive. It contains the basic toolchain (compiler, libraries, etc.) for building a complete system. You will unpack it to the hard drive as the "foundation" of the new system.

Portage (Wiki) Gentoo's package management system. It doesn't install pre-compiled packages directly, but downloads source code, compiles it according to your configuration, and then installs it. The core command is emerge.

USE Flags (Wiki) Switches that control software features. For example, USE="bluetooth" will enable Bluetooth functionality during compilation for all software that supports it. This is the core of Gentoo customization.

Profile (Wiki) Default system configuration template. For example, desktop/plasma/systemd profile will automatically enable default USE flags suitable for KDE Plasma desktop.

Emerge (Wiki) Portage's command-line tool. Common commands:

  • emerge --ask <package_name> - Install software
  • emerge --sync - Sync software repository
  • emerge -avuDN @world - Update the entire system
Installation Time Estimate (Click to expand)
StepEstimated Time
Prepare Installation Media10-15 mins
Disk Partitioning & Formatting15-30 mins
Download & Unpack Stage35-10 mins
Configure Portage & Profile15-20 mins
Compile Kernel (Most time-consuming)30 mins - 2 hours
Install System Tools20-40 mins
Configure Bootloader10-15 mins
Install Desktop Environment (Optional)1-3 hours
Total3-6 hours (Depends on hardware performance)

Tip

Using pre-compiled kernels and binary packages can significantly reduce time, but will sacrifice some customizability.

Disk Space Requirements & Pre-start Checklist (Click to expand)

Disk Space Requirements
#

  • Minimal Install: 10 GB (No desktop environment)
  • Recommended Space: 30 GB (Lightweight desktop)
  • Comfortable Space: 80 GB+ (Full desktop + compilation cache)

Pre-start Checklist
#

  • Backed up all important data
  • Prepared an 8GB+ USB flash drive
  • Confirmed stable network connection (Wired is best)
  • Reserved enough time (Recommended a full half-day)
  • Have some Linux command line basics
  • Prepared another device to consult documentation (Or use GUI LiveCD)

Guide Content Overview
#

This guide will lead you to install Gentoo Linux on x86_64 UEFI platform.

This article will teach you:

  • Install Gentoo base system from scratch (Partitioning, Stage3, Kernel, Bootloader)
  • Configure Portage and optimize compilation flags (make.conf, USE flags, CPU flags)
  • Install Desktop Environment (KDE Plasma, GNOME, Hyprland)
  • Configure Chinese Environment (locale, fonts, Fcitx5 input method)
  • Optional Advanced Configuration (LUKS full disk encryption, LTO optimization, Kernel tuning, RAID)
  • System Maintenance (SSD TRIM, Power Management, Flatpak, System Update)

Important Reminder

Please Disable Secure Boot First Before starting installation, please be sure to enter BIOS settings and temporarily disable Secure Boot. Enabling Secure Boot may cause installation media unable to boot, or installed system unable to boot. You can reconfigure and enable Secure Boot after system installation is complete and successfully booted, referring to later sections of this guide.

Backup All Important Data! This guide involves disk partitioning operations, please be sure to backup all important data before starting!

0. Prepare Installation Media
#

0.1 Download Gentoo ISO
#

Get download link according to Download Page

Note

The dates in the following links (e.g., 20251123T...) are for reference only, please be sure to select the latest date file in the mirror site.

Download Minimal ISO (Using official mirror as example):

wget https://distfiles.gentoo.org/releases/amd64/autobuilds/20251123T153051Z/install-amd64-minimal-20251123T153051Z.iso
wget https://distfiles.gentoo.org/releases/amd64/autobuilds/20251123T153051Z/install-amd64-minimal-20251123T153051Z.iso.asc

Beginner Recommendation: Use LiveGUI USB Image

If you hope to use a browser directly or connect Wi-Fi more conveniently during installation, you can choose LiveGUI USB Image.

Recommended for beginners to use weekly built KDE desktop environment Live ISO: https://iso.gig-os.org/ (From Gig-OS https://github.com/Gig-OS project)

Live ISO Login Credentials:

  • Account: live
  • Password: live
  • Root Password: live

System Support:

  • Supports Chinese display and Chinese input method (fcitx5), flclash etc.

Verify Signature (Optional):

# Get Gentoo Release Signing Key from keyserver
gpg --keyserver hkps://keys.openpgp.org --recv-keys 0xBB572E0E2D1829105A8D0F7CF7A88992
# --keyserver: Specify keyserver address
# --recv-keys: Receive and import public key
# 0xBB...992: Gentoo Release Media Signing Key Fingerprint

# Verify ISO file digital signature
gpg --verify install-amd64-minimal-20251123T153051Z.iso.asc install-amd64-minimal-20251123T153051Z.iso
# --verify: Verify signature file
# .iso.asc: Signature file (ASCII armored)
# .iso: ISO file to be verified

0.2 Create USB Installation Drive
#

Linux:

sudo dd if=install-amd64-minimal-20251123T153051Z.iso of=/dev/sdX bs=4M status=progress oflag=sync
# if=Input File of=Output Device bs=Block Size status=Show Progress

Tip

Please replace sdX with your USB device name, e.g., /dev/sdb.

Windows: Recommended to use Rufus → Select ISO → Select DD mode when writing.

1. Enter Live Environment and Connect Network
#

Why this step?

Gentoo installation process relies completely on network to download source packages (Stage3) and software repository (Portage). Configuring network in Live environment is the first step of installation.

1.1 Wired Network
#

ip link        # View network interface names (e.g. eno1, wlan0)
dhcpcd eno1    # Enable DHCP for wired interface to auto-get IP
ping -c3 gentoo.org # Test connectivity

1.2 Wireless Network
#

Use net-setup:

net-setup

wpa_supplicant:

wpa_passphrase "SSID" "PASSWORD" | tee /etc/wpa_supplicant/wpa_supplicant.conf
wpa_supplicant -B -i wlp0s20f3 -c /etc/wpa_supplicant/wpa_supplicant.conf
dhcpcd wlp0s20f3

Note

If WPA3 is unstable, please fallback to WPA2.

Advanced Setting: Start SSH for Remote Operation (Click to expand)
passwd                      # Set root password (required for remote login)
rc-service sshd start       # Start SSH service
rc-update add sshd default  # Set SSH auto-start (Optional in Live environment)
ip a | grep inet            # View current IP address
# On another device: ssh root@<IP>

2. Plan Disk Partitioning
#

Why this step?

We need to divide independent storage space for Linux system. UEFI systems usually need an ESP partition (Boot) and a Root partition (System). Reasonable planning makes future maintenance easier.

What is EFI System Partition (ESP)?
#

When installing Gentoo on a system booted by UEFI (instead of BIOS), creating an EFI System Partition (ESP) is necessary. ESP must be a FAT variant (sometimes shown as vfat on Linux systems). Official UEFI specification states UEFI firmware will recognize FAT12, 16 or 32 filesystems, but FAT32 is recommended.

Warning If ESP is not formatted using a FAT variant, the system's UEFI firmware will not find the bootloader (or Linux kernel) and will likely fail to boot the system!

Recommended Partition Scheme (UEFI)#

The table below provides a recommended default partition table for Gentoo trial installation.

Device PathMount PointFilesystemDescription
/dev/nvme0n1p1/efivfatEFI System Partition (ESP)
/dev/nvme0n1p2swapswapSwap Partition
/dev/nvme0n1p3/xfsRoot Partition

cfdisk Practical Example (Recommended)#

cfdisk is a graphical partition tool, simple and intuitive to operate.

cfdisk /dev/nvme0n1

Operation Tips:

  1. Select GPT label type.
  2. Create ESP: New partition -> Size 1G -> Type select EFI System.
  3. Create Swap: New partition -> Size 4G -> Type select Linux swap.
  4. Create Root: New partition -> Remaining space -> Type select Linux filesystem (Default).
  5. Select Write to write changes, type yes to confirm.
  6. Select Quit to exit.
                                                                 Disk: /dev/nvme0n1
                                              Size: 931.51 GiB, 1000204886016 bytes, 1953525168 sectors
                                            Label: gpt, identifier: 9737D323-129E-4B5F-9049-8080EDD29C02

    Device                                     Start                   End                  Sectors               Size Type
    /dev/nvme0n1p1                                34                  32767                 32734                16M Microsoft reserved
    /dev/nvme0n1p2                             32768              879779839             879747072             419.5G Microsoft basic data
    /dev/nvme0n1p3                        1416650752             1418747903               2097152                 1G EFI System
    /dev/nvme0n1p4                        1418747904             1437622271              18874368                 9G Linux swap
    /dev/nvme0n1p5                        1437622272             1953523711             515901440               246G Linux filesystem
>>  /dev/nvme0n1p6                         879779840             1416650751             536870912               256G Linux filesystem

 ┌─────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────┐
 │  Partition UUID: F2F1EF58-82EA-46A6-BF49-896AA40C6060                                                                                           │
 │  Partition type: Linux filesystem (0FC63DAF-8483-4772-8E79-3D69D8477DE4)                                                                        │
 │ Filesystem UUID: b4b0b42d-20be-4cf8-be81-9775efa6c151                                                                                           │
 │Filesystem LABEL: crypthomevar                                                                                                                   │
 │      Filesystem: crypto_LUKS                                                                                                                    │
 └─────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────────┘
                                   [ Delete ]  [Resize]  [ Quit ]  [ Type ]  [ Help ]  [ Sort ]  [ Write ]  [ Dump ]


                                                        Quit program without writing changes
Advanced Setting: fdisk Command Line Partitioning Tutorial (Click to expand)

fdisk is a powerful command line partition tool.

fdisk /dev/nvme0n1

1. View current partition layout

Use p key to show disk current partition configuration.

Command (m for help): p
Disk /dev/nvme0n1: 931.51 GiB, 1000204886016 bytes, 1953525168 sectors
Disk model: NVMe SSD
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disklabel type: gpt
Disk identifier: 3E56EE74-0571-462B-A992-9872E3855D75

Device           Start        End    Sectors   Size Type
/dev/nvme0n1p1    2048    2099199    2097152     1G EFI System
/dev/nvme0n1p2 2099200   10487807    8388608     4G Linux swap
/dev/nvme0n1p3 10487808 1953523711 1943035904 926.5G Linux root (x86-64)

2. Create a new disk label

Press g key to immediately delete all existing disk partitions and create a new GPT disk label:

Command (m for help): g
Created a new GPT disklabel (GUID: ...).

Or, to keep existing GPT disk label, use d key to delete existing partitions one by one.

3. Create EFI System Partition (ESP)

Type n to create a new partition, select partition number 1, start sector default (2048), end sector type +1G:

Command (m for help): n
Partition number (1-128, default 1): 1
First sector (2048-..., default 2048): <Enter>
Last sector, +/-sectors or +/-size{K,M,G,T,P} (...): +1G

Created a new partition 1 of type 'Linux filesystem' and of size 1 GiB.
Partition #1 contains a vfat signature.

Do you want to remove the signature? [Y]es/[N]o: Y
The signature will be removed by a write command.

Mark partition as EFI System Partition (Type code 1):

Command (m for help): t
Selected partition 1
Partition type or alias (type L to list all): 1
Changed type of partition 'Linux filesystem' to 'EFI System'.

4. Create Swap Partition

Create 4GB Swap partition:

Command (m for help): n
Partition number (2-128, default 2): 2
First sector (...): <Enter>
Last sector (...): +4G

Created a new partition 2 of type 'Linux filesystem' and of size 4 GiB.

Command (m for help): t
Partition number (1,2, default 2): 2
Partition type or alias (type L to list all): 19
Changed type of partition 'Linux filesystem' to 'Linux swap'.

(Note: Type 19 is Linux swap)

5. Create Root Partition

Allocate remaining space to Root partition:

Command (m for help): n
Partition number (3-128, default 3): 3
First sector (...): <Enter>
Last sector (...): <Enter>

Created a new partition 3 of type 'Linux filesystem' and of size 926.5 GiB.

Note

Setting root partition type to "Linux root (x86-64)" is not mandatory. System works fine if set to "Linux filesystem". This filesystem type is only needed when using a bootloader that supports it (i.e., systemd-boot) and not requiring fstab file.

Set partition type to "Linux root (x86-64)" (Type code 23):

Command (m for help): t
Partition number (1-3, default 3): 3
Partition type or alias (type L to list all): 23
Changed type of partition 'Linux filesystem' to 'Linux root (x86-64)'.

6. Write Changes

After checking, type w to write changes and exit:

Command (m for help): w
The partition table has been altered.
Calling ioctl() to re-read partition table.
Syncing disks.

3. Create Filesystem and Mount
#

Why this step?

Disk partitioning only divides space, but cannot store data yet. Creating filesystem (like ext4, Btrfs) allows OS to manage and access these spaces. Mounting connects these filesystems to specific locations in Linux file tree.

3.1 Formatting
#

mkfs.fat -F 32 /dev/nvme0n1p1  # Format ESP partition as FAT32
mkswap /dev/nvme0n1p2          # Format Swap partition
mkfs.xfs /dev/nvme0n1p3        # Format Root partition as XFS

If using Btrfs:

mkfs.btrfs -L gentoo /dev/nvme0n1p3

If using ext4:

mkfs.ext4 /dev/nvme0n1p3

Other Filesystems

For others like F2FS or ZFS, please refer to relevant Wiki.

3.2 Mounting (XFS Example)
#

mount /dev/nvme0n1p3 /mnt/gentoo        # Mount Root partition
mkdir -p /mnt/gentoo/efi                # Create ESP mount point
mount /dev/nvme0n1p1 /mnt/gentoo/efi    # Mount ESP partition
swapon /dev/nvme0n1p2                   # Enable Swap partition
Advanced Setting: Btrfs Subvolume Example (Click to expand)

1. Formatting

mkfs.fat -F 32 /dev/nvme0n1p1  # Format ESP
mkswap /dev/nvme0n1p2          # Format Swap
mkfs.btrfs -L gentoo /dev/nvme0n1p3 # Format Root (Btrfs)

2. Create Subvolumes

mount /dev/nvme0n1p3 /mnt/gentoo
btrfs subvolume create /mnt/gentoo/@
btrfs subvolume create /mnt/gentoo/@home
umount /mnt/gentoo

3. Mount Subvolumes

mount -o compress=zstd,subvol=@ /dev/nvme0n1p3 /mnt/gentoo
mkdir -p /mnt/gentoo/{efi,home}
mount -o subvol=@home /dev/nvme0n1p3 /mnt/gentoo/home
mount /dev/nvme0n1p1 /mnt/gentoo/efi    # Note: ESP must be FAT32 format
swapon /dev/nvme0n1p2

4. Verify Mount

lsblk

Output Example:

NAME             MAJ:MIN RM   SIZE RO TYPE  MOUNTPOINTS
nvme0n1          259:1    0 931.5G  0 disk
├─nvme0n1p1      259:7    0     1G  0 part  /mnt/gentoo/efi
├─nvme0n1p2      259:8    0     4G  0 part  [SWAP]
└─nvme0n1p3      259:9    0 926.5G  0 part  /mnt/gentoo/home
                                            /mnt/gentoo

Btrfs Snapshot Recommendation

Recommended to use Snapper to manage snapshots. Reasonable subvolume planning (like separating @ and @home) makes system rollback easier.

Advanced Setting: Encrypted Partition (LUKS) (Click to expand)

1. Create Encrypted Container

cryptsetup luksFormat --type luks2 --pbkdf argon2id --hash sha512 --key-size 512 /dev/nvme0n1p3

2. Open Encrypted Container

cryptsetup luksOpen /dev/nvme0n1p3 gentoo-root

3. Formatting

mkfs.fat -F 32 /dev/nvme0n1p1       # Format ESP
mkswap /dev/nvme0n1p2               # Format Swap
mkfs.btrfs --label root /dev/mapper/gentoo-root # Format Root (Btrfs)

4. Mounting

mount /dev/mapper/gentoo-root /mnt/gentoo
mkdir -p /mnt/gentoo/efi
mount /dev/nvme0n1p1 /mnt/gentoo/efi
swapon /dev/nvme0n1p2

5. Verify Mount

lsblk

Output Example:

NAME             MAJ:MIN RM   SIZE RO TYPE  MOUNTPOINTS
nvme0n1          259:1    0 931.5G  0 disk
├─nvme0n1p1      259:7    0     1G  0 part  /mnt/gentoo/efi
├─nvme0n1p2      259:8    0     4G  0 part  [SWAP]
└─nvme0n1p3      259:9    0 926.5G  0 part
  └─gentoo-root  253:0    0 926.5G  0 crypt /mnt/gentoo

Recommendation

After mounting, recommended to use lsblk to confirm mount points are correct.

lsblk

Output Example (Similar to below):

NAME             MAJ:MIN RM   SIZE RO TYPE  MOUNTPOINTS
 nvme0n1          259:1    0 931.5G  0 disk
├─nvme0n1p1      259:7    0     1G  0 part  /efi
├─nvme0n1p2      259:8    0     4G  0 part  [SWAP]
└─nvme0n1p3      259:9    0 926.5G  0 part  /

4. Download Stage3 and Enter chroot
#

Why this step?

Stage3 is a minimal Gentoo base system environment. We will unpack it to the hard drive as the "foundation" of the new system, and then enter this new environment via chroot for subsequent configuration.

4.1 Select Stage3
#

  • OpenRC: stage3-amd64-openrc-*.tar.xz
  • systemd: stage3-amd64-systemd-*.tar.xz
  • Desktop variants just pre-enable some USE flags, standard version is more flexible.

4.2 Download and Unpack
#

cd /mnt/gentoo
# Use links browser to visit mirror site to download Stage3
links https://distfiles.gentoo.org/releases/amd64/autobuilds/20251123T153051Z/ # Using official mirror as example
# Unpack Stage3 archive
# x:extract p:preserve permissions v:verbose f:file --numeric-owner:use numeric IDs
tar xpvf stage3-*.tar.xz --xattrs-include='*.*' --numeric-owner

If downloaded .DIGESTS or .CONTENTS as well, can verify with openssl or gpg.

4.3 Copy DNS and Mount Pseudo-filesystems
#

cp --dereference /etc/resolv.conf /mnt/gentoo/etc/ # Copy DNS config
mount --types proc /proc /mnt/gentoo/proc          # Mount process info
mount --rbind /sys /mnt/gentoo/sys                 # Bind mount system info
mount --rbind /dev /mnt/gentoo/dev                 # Bind mount device nodes
mount --rbind /run /mnt/gentoo/run                 # Bind mount runtime info
mount --make-rslave /mnt/gentoo/sys                # Set as slave mount (prevent unmount affecting host)
mount --make-rslave /mnt/gentoo/dev
mount --make-rslave /mnt/gentoo/run

Using OpenRC can omit /run step.

4.4 Enter chroot
#

chroot /mnt/gentoo /bin/bash    # Switch root directory to new system
source /etc/profile             # Load environment variables
export PS1="(chroot) ${PS1}"    # Modify prompt to distinguish environment

5. Initialize Portage and make.conf
#

Why is this step needed?

Portage is Gentoo's package management system and its core feature. Initializing Portage and configuring make.conf is like setting a "build blueprint" for your new system, determining how software is compiled, which features to use, and where to download from.

5.1 Sync Portage Tree
#

emerge-webrsync   # Get latest Portage snapshot (faster than rsync)
emerge --sync     # Sync Portage tree (get latest ebuilds)
emerge --ask app-editors/vim # Install Vim editor (recommended)
eselect editor list          # List available editors
eselect editor set vi        # Set Vim as default editor (vi is usually a symlink to vim)

Set mirrors (choose one):

mirrorselect -i -o >> /etc/portage/make.conf
# Or manually:
# Using official Gentoo mirrors as example
echo 'GENTOO_MIRRORS="https://distfiles.gentoo.org/"' >> /etc/portage/make.conf

5.2 make.conf Example
#

Edit /etc/portage/make.conf:

vim /etc/portage/make.conf

Lazy/Beginner Configuration (Copy & Paste):

Tip

Please adjust the -j parameter in MAKEOPTS according to your CPU core count (e.g., use -j8 for 8-core CPU).

COMMON_FLAGS="-march=native -O2 -pipe"
CFLAGS="${COMMON_FLAGS}"
CXXFLAGS="${COMMON_FLAGS}"
FCFLAGS="${COMMON_FLAGS}"
FFLAGS="${COMMON_FLAGS}"
MAKEOPTS="-j8"
USE="X wayland pulseaudio"
ACCEPT_LICENSE="*"
ACCEPT_KEYWORDS="~amd64"
L10N="en en-US"
VIDEO_CARDS="amdgpu radeonsi intel i965 iris nouveau nvidia"
INPUT_DEVICES="libinput"
GENTOO_MIRRORS="https://distfiles.gentoo.org/"

Important

This configuration does NOT enable LTO, ccache optimization. If you want advanced optimization, please refer to 13. make.conf Advanced Configuration Guide.

Detailed Configuration (Click to expand)

Edit /etc/portage/make.conf:

Note

Setting root partition type to "Linux root (x86-64)" is not mandatory. System works fine if set to "Linux filesystem". This filesystem type is only needed when using a bootloader that supports it (i.e., systemd-boot) and not requiring fstab file.

Set partition type to "Linux root (x86-64)" (Type code 23):

Command (m for help): t
Partition number (1-3, default 3): 3
Partition type or alias (type L to list all): 23
Changed type of partition 'Linux filesystem' to 'Linux root (x86-64)'.

6. Write Changes

After checking, type w to write changes and exit:

Command (m for help): w
The partition table has been altered.
Calling ioctl() to re-read partition table.
Syncing disks.

3. Create Filesystem and Mount
#

Why this step?

Disk partitioning only divides space, but cannot store data yet. Creating filesystem (like ext4, Btrfs) allows OS to manage and access these spaces. Mounting connects these filesystems to specific locations in Linux file tree.

3.1 Formatting
#

mkfs.fat -F 32 /dev/nvme0n1p1  # Format ESP partition as FAT32
mkswap /dev/nvme0n1p2          # Format Swap partition
mkfs.xfs /dev/nvme0n1p3        # Format Root partition as XFS

If using Btrfs:

mkfs.btrfs -L gentoo /dev/nvme0n1p3

If using ext4:

mkfs.ext4 /dev/nvme0n1p3

Other Filesystems

For others like F2FS or ZFS, please refer to relevant Wiki.

3.2 Mounting (XFS Example)
#

mount /dev/nvme0n1p3 /mnt/gentoo        # Mount Root partition
mkdir -p /mnt/gentoo/efi                # Create ESP mount point
mount /dev/nvme0n1p1 /mnt/gentoo/efi    # Mount ESP partition
swapon /dev/nvme0n1p2                   # Enable Swap partition
Advanced Setting: Btrfs Subvolume Example (Click to expand)

1. Formatting

mkfs.fat -F 32 /dev/nvme0n1p1  # Format ESP
mkswap /dev/nvme0n1p2          # Format Swap
mkfs.btrfs -L gentoo /dev/nvme0n1p3 # Format Root (Btrfs)

2. Create Subvolumes

mount /dev/nvme0n1p3 /mnt/gentoo
btrfs subvolume create /mnt/gentoo/@
btrfs subvolume create /mnt/gentoo/@home
umount /mnt/gentoo

3. Mount Subvolumes

mount -o compress=zstd,subvol=@ /dev/nvme0n1p3 /mnt/gentoo
mkdir -p /mnt/gentoo/{efi,home}
mount -o subvol=@home /dev/nvme0n1p3 /mnt/gentoo/home
mount /dev/nvme0n1p1 /mnt/gentoo/efi    # Note: ESP must be FAT32 format
swapon /dev/nvme0n1p2

4. Verify Mount

lsblk

Output Example:

NAME             MAJ:MIN RM   SIZE RO TYPE  MOUNTPOINTS
nvme0n1          259:1    0 931.5G  0 disk
├─nvme0n1p1      259:7    0     1G  0 part  /mnt/gentoo/efi
├─nvme0n1p2      259:8    0     4G  0 part  [SWAP]
└─nvme0n1p3      259:9    0 926.5G  0 part  /mnt/gentoo/home
                                            /mnt/gentoo

Btrfs Snapshot Recommendation

Recommended to use Snapper to manage snapshots. Reasonable subvolume planning (like separating @ and @home) makes system rollback easier.

Advanced Setting: Encrypted Partition (LUKS) (Click to expand)

1. Create Encrypted Container

cryptsetup luksFormat --type luks2 --pbkdf argon2id --hash sha512 --key-size 512 /dev/nvme0n1p3

2. Open Encrypted Container

cryptsetup luksOpen /dev/nvme0n1p3 gentoo-root

3. Formatting

mkfs.fat -F 32 /dev/nvme0n1p1       # Format ESP
mkswap /dev/nvme0n1p2               # Format Swap
mkfs.btrfs --label root /dev/mapper/gentoo-root # Format Root (Btrfs)

4. Mounting

mount /dev/mapper/gentoo-root /mnt/gentoo
mkdir -p /mnt/gentoo/efi
mount /dev/nvme0n1p1 /mnt/gentoo/efi
swapon /dev/nvme0n1p2

5. Verify Mount

lsblk

Output Example:

NAME             MAJ:MIN RM   SIZE RO TYPE  MOUNTPOINTS
nvme0n1          259:1    0 931.5G  0 disk
├─nvme0n1p1      259:7    0     1G  0 part  /mnt/gentoo/efi
├─nvme0n1p2      259:8    0     4G  0 part  [SWAP]
└─nvme0n1p3      259:9    0 926.5G  0 part
  └─gentoo-root  253:0    0 926.5G  0 crypt /mnt/gentoo

Recommendation

After mounting, recommended to use lsblk to confirm mount points are correct.

lsblk

Output Example (Similar to below):

NAME             MAJ:MIN RM   SIZE RO TYPE  MOUNTPOINTS
 nvme0n1          259:1    0 931.5G  0 disk
├─nvme0n1p1      259:7    0     1G  0 part  /efi
├─nvme0n1p2      259:8    0     4G  0 part  [SWAP]
└─nvme0n1p3      259:9    0 926.5G  0 part  /

4. Download Stage3 and Enter chroot
#

Why this step?

Stage3 is a minimal Gentoo base system environment. We will unpack it to the hard drive as the "foundation" of the new system, and then enter this new environment via chroot for subsequent configuration.

4.1 Select Stage3
#

  • OpenRC: stage3-amd64-openrc-*.tar.xz
  • systemd: stage3-amd64-systemd-*.tar.xz
  • Desktop variants just pre-enable some USE flags, standard version is more flexible.

4.2 Download and Unpack
#

cd /mnt/gentoo
# Use links browser to visit mirror site to download Stage3
links https://distfiles.gentoo.org/releases/amd64/autobuilds/20251123T153051Z/ # Using official mirror as example
# Unpack Stage3 archive
# x:extract p:preserve permissions v:verbose f:file --numeric-owner:use numeric IDs
tar xpvf stage3-*.tar.xz --xattrs-include='*.*' --numeric-owner

If downloaded .DIGESTS or .CONTENTS as well, can verify with openssl or gpg.

4.3 Copy DNS and Mount Pseudo-filesystems
#

cp --dereference /etc/resolv.conf /mnt/gentoo/etc/ # Copy DNS config
mount --types proc /proc /mnt/gentoo/proc          # Mount process info
mount --rbind /sys /mnt/gentoo/sys                 # Bind mount system info
mount --rbind /dev /mnt/gentoo/dev                 # Bind mount device nodes
mount --rbind /run /mnt/gentoo/run                 # Bind mount runtime info
mount --make-rslave /mnt/gentoo/sys                # Set as slave mount (prevent unmount affecting host)
mount --make-rslave /mnt/gentoo/dev
mount --make-rslave /mnt/gentoo/run

Using OpenRC can omit /run step.

4.4 Enter chroot
#

chroot /mnt/gentoo /bin/bash    # Switch root directory to new system
source /etc/profile             # Load environment variables
export PS1="(chroot) ${PS1}"    # Modify prompt to distinguish environment

5. Initialize Portage and make.conf
#

Why this step?

Portage is Gentoo's package management system and its core feature. Initializing Portage and configuring make.conf is like setting the "building blueprint" for your new system, deciding how software is compiled, what features to use, and where to download from.

5.1 Sync Tree
#

emerge-webrsync   # Get latest Portage snapshot (faster than rsync)
emerge --sync     # Sync Portage tree (get latest ebuilds)
emerge --ask app-editors/vim # Install Vim editor (Recommended)
eselect editor list          # List available editors
eselect editor set vi        # Set Vim as default editor (vi is usually a symlink to vim)

Set mirror (Choose one):

mirrorselect -i -o >> /etc/portage/make.conf
# Or manually:
# Using official mirror as example
echo 'GENTOO_MIRRORS="https://distfiles.gentoo.org/"' >> /etc/portage/make.conf

5.2 make.conf Example
#

Edit /etc/portage/make.conf:

vim /etc/portage/make.conf

Lazy/Beginner Config (Copy Paste):

Tip

Please modify the -j parameter in MAKEOPTS according to your CPU core count (e.g., 8-core CPU use -j8).

COMMON_FLAGS="-march=native -O2 -pipe"
CFLAGS="${COMMON_FLAGS}"
CXXFLAGS="${COMMON_FLAGS}"
FCFLAGS="${COMMON_FLAGS}"
FFLAGS="${COMMON_FLAGS}"

# Please modify number after -j according to CPU core count
MAKEOPTS="-j8"

# Language Setting
LC_MESSAGES=C
L10N="en en-US"
LINGUAS="en en_US"

# Mirror Source (Official)
GENTOO_MIRRORS="https://distfiles.gentoo.org/"

# Common USE flags (Recommended for systemd users)
USE="systemd udev dbus policykit networkmanager bluetooth git dist-kernel"
ACCEPT_LICENSE="*"
Detailed Config Example (Recommended to read and adjust) (Click to expand)
# vim: set language=bash;  # Tell Vim to use bash syntax highlighting
CHOST="x86_64-pc-linux-gnu"  # Target system architecture (Do not modify manually)

# ========== Compilation Optimization Flags ==========
# -march=native: Optimize for current CPU (Recommended, best performance)
# -O2: Optimization level 2 (Balance performance and stability, Recommended)
# -pipe: Use pipes to pass data, speed up compilation (Does not affect final program)
COMMON_FLAGS="-march=native -O2 -pipe"
CFLAGS="${COMMON_FLAGS}"    # C program compilation flags
CXXFLAGS="${COMMON_FLAGS}"  # C++ program compilation flags
FCFLAGS="${COMMON_FLAGS}"   # Fortran program compilation flags
FFLAGS="${COMMON_FLAGS}"    # Fortran 77 program compilation flags

# CPU Instruction Set Optimization (See section 5.3 below, run cpuid2cpuflags to generate automatically)
# CPU_FLAGS_X86="aes avx avx2 ..."

# ========== Language and Localization Settings ==========
# Keep build output in English (Easier for troubleshooting and searching solutions)
LC_MESSAGES=C

# L10N: Localization support (Affects documentation, translations, etc.)
L10N="en en-US"
# LINGUAS: Legacy localization variable (Still needed by some software)
LINGUAS="en en_US"

# ========== Parallel Compilation Settings ==========
# Number after -j = CPU thread count (e.g. 32 core CPU use -j32)
# Recommended value: CPU thread count (Check via nproc command)
MAKEOPTS="-j32"  # Please adjust according to actual hardware

# ========== Mirror Source Settings ==========
# Gentoo software package download mirror (Recommended to choose appropriate mirror for acceleration)
GENTOO_MIRRORS="https://distfiles.gentoo.org/"

# ========== Emerge Default Options ==========
# --ask: Ask for confirmation before execution
# --verbose: Show detailed info (USE flag changes etc.)
# --with-bdeps=y: Include build-time dependencies
# --complete-graph=y: Complete dependency graph analysis
EMERGE_DEFAULT_OPTS="--ask --verbose --with-bdeps=y --complete-graph=y"

# ========== USE Flags (Global Feature Switches) ==========
# systemd: Use systemd as init system (If using OpenRC change to -systemd)
# udev: Device management support
# dbus: Inter-process communication (Required for desktop environment)
# policykit: Permission management (Required for desktop environment)
# networkmanager: Network Manager (Recommended)
# bluetooth: Bluetooth support
# git: Git version control
# dist-kernel: Use distribution kernel (Recommended for beginners, can use pre-compiled kernel)
USE="systemd udev dbus policykit networkmanager bluetooth git dist-kernel"

# ========== License Acceptance ==========
# "*" means accept all licenses (including non-free software licenses)
# Optionally accept: ACCEPT_LICENSE="@FREE" (Only free software)
ACCEPT_LICENSE="*"

# Keep newline at end of file! Important!

Beginner Tip

  • The number in MAKEOPTS="-j32" should be your CPU thread count, check via nproc command
  • If memory is insufficient during compilation, reduce parallel task count (e.g. change to -j16)
  • USE flags are Gentoo's core feature, deciding what features are included when compiling software
Advanced Setting: CPU Instruction Set Optimization (CPU_FLAGS_X86) (Click to expand)

Reference: CPU_FLAGS_*

To let Portage know which specific instruction sets your CPU supports (like AES, AVX, SSE4.2 etc.), we need to configure CPU_FLAGS_X86.

Install detection tool:

emerge --ask app-portage/cpuid2cpuflags # Install detection tool

Run detection and write to config:

cpuid2cpuflags >> /etc/portage/make.conf # Append detection result to config file

Check end of /etc/portage/make.conf, you should see a line similar to this:

CPU_FLAGS_X86="aes avx avx2 f16c fma3 mmx mmxext pclmul popcnt rdrand sse sse2 sse3 sse4_1 sse4_2 ssse3"

6. Profile, System Settings and Localization
#

Why this step?

Profile defines system base configuration and default USE flags, embodying Gentoo's flexibility. Configuring timezone, language and network basic system parameters is key to making your Gentoo system work properly and fit personal usage habits.

6.1 Select Profile
#

eselect profile list          # List all available Profiles
eselect profile set <number>    # Set selected Profile
emerge -avuDN @world          # Update system to match new Profile (a:ask v:verbose u:update D:deep N:newUSE)

Common options:

  • default/linux/amd64/23.0/desktop/plasma/systemd
  • default/linux/amd64/23.0/desktop/gnome/systemd
  • default/linux/amd64/23.0/desktop (OpenRC desktop)

6.2 Timezone and Locale
#

echo "Asia/Shanghai" > /etc/timezone
emerge --config sys-libs/timezone-data

echo "en_US.UTF-8 UTF-8" > /etc/locale.gen
echo "zh_CN.UTF-8 UTF-8" >> /etc/locale.gen
locale-gen                      # Generate selected locales
eselect locale set en_US.utf8   # Set system default locale (Recommended to use English to avoid garbled text)

# Reload environment
env-update && source /etc/profile && export PS1="(chroot) ${PS1}"

6.3 Hostname and Network Settings
#

Set Hostname:

echo "gentoo" > /etc/hostname

Network Management Tool Selection:

Option A: NetworkManager (Recommended, General Purpose)

Reference: NetworkManager

Suitable for most desktop users, supports both OpenRC and systemd.

emerge --ask net-misc/networkmanager
# OpenRC:
rc-update add NetworkManager default
# systemd:
systemctl enable NetworkManager

Configuration Tip

GUI: Run nm-connection-editor Command Line: Use nmtui (Graphical wizard) or nmcli

Advanced Tip: Use iwd backend (Click to expand)

NetworkManager supports using iwd as backend (faster than wpa_supplicant).

echo "net-misc/networkmanager iwd" >> /etc/portage/package.use/networkmanager
emerge --ask --newuse net-misc/networkmanager

Then edit /etc/NetworkManager/NetworkManager.conf, add wifi.backend=iwd under [device].

Option B: Lightweight Solution (Click to expand)

If you don't want to use NetworkManager, you can choose the following lightweight solutions:

  1. Wired Network (dhcpcd)

Reference: dhcpcd

emerge --ask net-misc/dhcpcd
# OpenRC:
rc-update add dhcpcd default
# systemd:
systemctl enable dhcpcd
  1. Wireless Network (iwd)

Reference: iwd

emerge --ask net-wireless/iwd
# OpenRC:
rc-update add iwd default
# systemd:
systemctl enable iwd

Tip: iwd is a modern, lightweight wireless daemon.

Option 3: Native Solution (Click to expand)

Use init system's built-in network management features, suitable for servers or minimal environments.

OpenRC Network Service:

vim /etc/conf.d/net

Note

Please replace enp5s0 below with your actual network interface name (check via ip link).

Write the following content:

config_enp5s0="dhcp"

ln -s /etc/init.d/net.lo /etc/init.d/net.enp5s0 # Create network service symlink
rc-update add net.enp5s0 default                # Set auto-start

Systemd Native Network Service:

Systemd comes with built-in network management features, suitable for servers or minimal environments:

systemctl enable systemd-networkd
systemctl enable systemd-resolved

Note: Need to manually write .network config files.

6.4 Configure fstab
#

Get UUID:

blkid

Method A: Auto Generate (Recommended for LiveGUI users)

Note

genfstab tool is usually included in arch-install-scripts package. If you are using Gig-OS or other Arch-based LiveISO, you can use it directly. Official Minimal ISO may need manual installation or use Method B.

emerge --ask sys-fs/genfstab # If command not found
genfstab -U /mnt/gentoo >> /mnt/gentoo/etc/fstab

Check generated file:

cat /mnt/gentoo/etc/fstab

Method B: Manual Edit

Edit /etc/fstab:

vim /etc/fstab

# <fs>                                     <mountpoint> <type> <opts>            <dump/pass>
UUID=7E91-5869                             /efi         vfat   defaults,noatime  0 2
UUID=7fb33b5d-4cff-47ff-ab12-7b461b5d6e13  none         swap   sw                0 0
UUID=8c08f447-c79c-4fda-8c08-f447c79ce690  /            xfs    defaults,noatime  0 1
Advanced Setting: Btrfs fstab Example (Click to expand)
# Root Subvolume
UUID=7b44c5eb-caa0-413b-9b7e-a991e1697465  /            btrfs  defaults,noatime,compress=zstd:3,discard=async,space_cache=v2,commit=60,subvol=@              0 0

# Home Subvolume
UUID=7b44c5eb-caa0-413b-9b7e-a991e1697465  /home        btrfs  defaults,noatime,compress=zstd:3,discard=async,space_cache=v2,commit=60,subvol=@home          0 0

# Swap
UUID=7fb33b5d-4cff-47ff-ab12-7b461b5d6e13  none         swap   sw                                                      0 0

# ESP (UEFI)
UUID=7E91-5869                             /efi         vfat   defaults,noatime,fmask=0022,dmask=0022                  0 2

Note

Please be sure to use blkid command to get your actual UUID and replace the example values above.

Advanced Setting: LUKS Encrypted Partition fstab Example (Click to expand)

Key Point

In fstab, you MUST use the UUID of the Decrypted Mapped Device, not the UUID of the Physical Partition (LUKS Container).

1. Check UUID Difference

blkid

Output Example (Note difference between crypto_LUKS and btrfs):

# This is physical partition (LUKS container), DO NOT use this UUID in fstab!
/dev/nvme0n1p5: UUID="562d0251-..." TYPE="crypto_LUKS" ...

# This is decrypted mapped device (filesystem), fstab should use this UUID!
/dev/mapper/cryptroot: UUID="7b44c5eb-..." TYPE="btrfs" ...

2. fstab Config Example

# Root (Btrfs inside LUKS) - Use UUID of /dev/mapper/cryptroot
UUID=7b44c5eb-caa0-413b-9b7e-a991e1697465  /            btrfs  defaults,noatime,compress=zstd:3,discard=async,space_cache=v2,commit=60,subvol=@              0 0

# Home (Btrfs inside LUKS) - Use UUID of /dev/mapper/crypthomevar
UUID=4ad44bb7-9843-470b-9a88-f008367b63a3  /home        btrfs  defaults,noatime,compress=zstd:3,discard=async,space_cache=v2,commit=60,subvol=@home          0 0

# Swap
UUID=7fb33b5d-4cff-47ff-ab12-7b461b5d6e13  none         swap   sw                                                      0 0

# ESP (UEFI)
UUID=7E91-5869                             /efi         vfat   defaults,noatime,fmask=0022,dmask=0022                  0 2

7. Kernel and Firmware
#

Why this step?

The kernel is the core of the operating system, responsible for managing hardware. Gentoo allows you to manually tailor the kernel, keeping only the drivers you need, thus obtaining extreme performance and minimal size. Beginners can also choose pre-compiled kernels to get started quickly.

7.1 Quick Solution: Pre-compiled Kernel
#

emerge --ask sys-kernel/gentoo-kernel-bin

Remember to regenerate bootloader configuration after kernel upgrade.

Advanced Setting: Manual Kernel Compilation (Gentoo Kernel Experience) (Click to expand)

Beginner Tip

Compiling kernel is complex and time-consuming. If you want to experience Gentoo as soon as possible, you can skip this section first and use pre-compiled kernel in 7.1.

Manual kernel compilation allows you to fully control system features, remove unneeded drivers, and get a leaner, more efficient kernel.

Quick Start (Using Genkernel automation):

emerge --ask sys-kernel/gentoo-sources sys-kernel/genkernel
genkernel --install all  # Automatically compile and install kernel, modules and initramfs
# --install: Automatically install to /boot directory after compilation
# all: Full build (kernel + modules + initramfs)

Advanced Content

If you want to deeply understand kernel configuration, use LLVM/Clang to compile kernel, enable LTO optimization and other advanced options, please refer to Section 16.0 Kernel Compilation Advanced Guide.

7.3 Install Firmware and Microcode
#

mkdir -p /etc/portage/package.license
# Accept Linux firmware license terms
echo 'sys-kernel/linux-firmware linux-fw-redistributable no-source-code' > /etc/portage/package.license/linux-firmware
echo 'sys-kernel/installkernel dracut' > /etc/portage/package.use/installkernel
emerge --ask sys-kernel/linux-firmware
emerge --ask sys-firmware/intel-microcode  # Intel CPU

8. Base Tools
#

Why this step?

Stage3 only has the most basic commands. We need to supplement system logger, network management, filesystem tools and other necessary components so that the system can work properly after reboot.

8.1 System Service Tools
#

OpenRC Users (Required):

1. System Logger

Reference: Syslog-ng

emerge --ask app-admin/syslog-ng
rc-update add syslog-ng default

2. Cron Job

emerge --ask sys-process/cronie
rc-update add cronie default

3. Time Sync

emerge --ask net-misc/chrony
rc-update add chronyd default

systemd Users: systemd has built-in logger and time sync services.

Time Sync

systemctl enable --now systemd-timesyncd

8.3 Filesystem Tools
#

Install corresponding tools according to the filesystem you use (Required):

emerge --ask sys-fs/e2fsprogs  # ext4
emerge --ask sys-fs/xfsprogs   # XFS
emerge --ask sys-fs/dosfstools # FAT/vfat (Required for EFI partition)
emerge --ask sys-fs/btrfs-progs # Btrfs

9. Create User and Permissions
#

Why this step?

Linux does not recommend using root account for daily use. We need to create a normal user and grant it permission to use sudo to improve system security.

passwd root # Set root password
useradd -m -G wheel,video,audio,plugdev zakk # Create user and add to common groups
passwd zakk # Set user password
emerge --ask app-admin/sudo
echo "%wheel ALL=(ALL) ALL" > /etc/sudoers.d/wheel # Allow wheel group to use sudo

If using systemd, can add account to network, lp groups as needed.

10. Install Bootloader
#

10.1 GRUB
#

Reference: GRUB

emerge --ask sys-boot/grub:2
mkdir -p /efi/EFI/Gentoo
grub-install --target=x86_64-efi --efi-directory=/efi --bootloader-id=Gentoo # Install GRUB to ESP
# Install os-prober to support multi-system detection
emerge --ask sys-boot/os-prober

# Enable os-prober (For detecting Windows and other OS)
echo 'GRUB_DISABLE_OS_PROBER=false' >> /etc/default/grub

# Generate GRUB config file
grub-mkconfig -o /boot/grub/grub.cfg
Advanced Setting: systemd-boot (UEFI Only) (Click to expand)

Reference: systemd-boot

bootctl --path=/efi install # Install systemd-boot
# 1. Create Gentoo Boot Entry
vim /efi/loader/entries/gentoo.conf

Write the following content (Note to replace UUID):

title   Gentoo Linux
linux   /vmlinuz-6.6.62-gentoo-dist
initrd  /initramfs-6.6.62-gentoo-dist.img
options root=UUID=xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx rw quiet

Note

If you used LUKS encryption, options line needs to add rd.luks.uuid=... and other parameters.

2. Update Boot Entry: After every kernel update, need to manually update version number in gentoo.conf, or use script to automate.

2. Create Windows Boot Entry (Dual Boot)

Tip

If you created a new EFI partition, please remember to copy original Windows EFI files (EFI/Microsoft) to the new partition.

vim /efi/loader/entries/windows.conf

Write the following content:

title      Windows 11
sort-key   windows-01
efi        /EFI/Microsoft/Boot/bootmgfw.efi

3. Configure Default Boot
#

vim /efi/loader/loader.conf

Write the following content:

default gentoo.conf
timeout 3
console-mode auto
Advanced Setting: Encryption Support (Encrypted Users Only) (Click to expand)

Reference: Dm-crypt

Note

Only execute this step if you selected encrypted partition in Step 3.4.

Step 1: Enable systemd cryptsetup support

mkdir -p /etc/portage/package.use
echo "sys-apps/systemd cryptsetup" >> /etc/portage/package.use/fde

# Recompile systemd to enable cryptsetup support
emerge --ask --oneshot sys-apps/systemd

Step 2: Get UUID of LUKS Partition

# Get UUID of LUKS encrypted container (Not the filesystem inside)
blkid /dev/nvme0n1p3

Output Example:

/dev/nvme0n1p3: UUID="a1b2c3d4-e5f6-7890-abcd-ef1234567890" TYPE="crypto_LUKS" ...

Note down this LUKS UUID (e.g.: a1b2c3d4-e5f6-7890-abcd-ef1234567890).

Step 3: Configure GRUB Kernel Parameters

vim /etc/default/grub

Add or modify the following content (Replace UUID with actual value):

# Full Example (Replace UUID with your actual UUID)
GRUB_CMDLINE_LINUX="rd.luks.uuid=<LUKS-UUID> rd.luks.allow-discards root=UUID=<ROOT-UUID> rootfstype=btrfs"

Parameter Explanation:

  • rd.luks.uuid=<UUID>: UUID of LUKS encrypted partition (Get via blkid /dev/nvme0n1p3)
  • rd.luks.allow-discards: Allow SSD TRIM command to pass through encryption layer (Improve SSD performance)
  • root=UUID=<UUID>: UUID of decrypted btrfs filesystem (Get via blkid /dev/mapper/gentoo-root)
  • rootfstype=btrfs: Root filesystem type (Change to ext4 if using ext4)
Step 3.1 (Alternative): Configure Kernel Parameters (systemd-boot Solution) (Click to expand)

If you use systemd-boot instead of GRUB, please edit config files under /boot/loader/entries/ (e.g. gentoo.conf):

title      Gentoo Linux
version    6.6.13-gentoo
options    rd.luks.name=<LUKS-UUID>=cryptroot root=/dev/mapper/cryptroot rootfstype=btrfs rd.luks.allow-discards init=/lib/systemd/systemd
linux      /vmlinuz-6.6.13-gentoo
initrd     /initramfs-6.6.13-gentoo.img

Parameter Explanation:

  • rd.luks.name=<LUKS-UUID>=cryptroot: Specify LUKS partition UUID and map as cryptroot.
  • root=/dev/mapper/cryptroot: Specify decrypted root partition device.
  • rootfstype=btrfs: Specify root filesystem type.

Step 4: Install and Configure dracut

Reference: Dracut · Initramfs

# Install dracut (If not installed)
emerge --ask sys-kernel/dracut

Step 5: Configure dracut for LUKS Decryption

Create dracut config file:

vim /etc/dracut.conf.d/luks.conf

Add following content:

# Do not set kernel_cmdline here, GRUB will override it
kernel_cmdline=""
# Add necessary modules to support LUKS + btrfs
add_dracutmodules+=" btrfs systemd crypt dm "
# Add necessary tools
install_items+=" /sbin/cryptsetup /bin/grep "
# Specify filesystem (Modify if using other filesystem)
filesystems+=" btrfs "

Configuration Explanation:

  • crypt and dm modules provide LUKS decryption support
  • systemd module used for systemd boot environment
  • btrfs module supports btrfs filesystem (Change to ext4 if using ext4)

Step 6: Configure /etc/crypttab (Optional but Recommended)#

vim /etc/crypttab

Add following content (Replace UUID with your LUKS UUID):

gentoo-root UUID=<LUKS-UUID> none luks,discard

With this configuration, system will automatically recognize and prompt to unlock encrypted partition.

Step 7: Regenerate initramfs
#

dracut --kver $(make -C /usr/src/linux -s kernelrelease) --force
# --kver: Specify kernel version
# $(make -C /usr/src/linux -s kernelrelease): Automatically get current kernel version
# --force: Force overwrite existing initramfs file

Important: After every kernel update, also need to execute this command to generate new initramfs!

Step 8: Update GRUB Config
#

grub-mkconfig -o /boot/grub/grub.cfg

# Verify initramfs is correctly referenced
grep initrd /boot/grub/grub.cfg

11. Pre-reboot Checklist and Reboot
#

  1. emerge --info executes normally without error
  2. UUID in /etc/fstab is correct (Confirm with blkid again)
  3. Root and normal user passwords set
  4. grub-mkconfig executed or bootctl configuration completed
  5. If using LUKS, confirm initramfs contains cryptsetup

Leave chroot and reboot:

exit
umount -l /mnt/gentoo/dev{/shm,/pts,}
umount -R /mnt/gentoo
swapoff -a
reboot

Congratulations! You have completed Gentoo base installation.

Next Step: Desktop Configuration

Related

About

About

··3 mins· loading
Zakk
Timeline

Timeline

··2 mins· loading
Zakk
